Smeg KSEG78PXE Undercabinet built-in hood vent 74cm stainless steel

INTENSIVE SPEED

The intensive function allows you to operate the hood at maximum power, to speed up the elimination of the most persistent odors and have a purified environment.

PERIMETER SUCTION

The suction of the hood is concentrated on the peripheral area, so as to allow for a larger suction surface and offer a better level of silence, limiting the vibrations of the filters.

TYPE

Family: Hood

Type: Integrated into group

Hood width: 77 cm

Filtering: Expulsion

Electronic control: Yes

Perimeter extraction: Yes

EAN code : 8017709224905

ESTETIC

Colour: Stainless Steel

Finish: Satin

Aesthetics: Universal

Design: Concealed

Material: Stainless steel

Type of stainless steel: Satin

PROGRAMS / FUNCTIONS

No. of speeds: 3

Intensive speed: Yes

Time programming options: Automatic switch-off

CONTROLS

Control adjustment: Electronic keys

LED colour : White

TECHNICAL SPECIFICATIONS

Anti-grease filters: The anti-grease filters purify the air of cooking fats. They are easily disassembled for their periodic cleaning. Light: The hoods are equipped with LED lamps. The light can be turned on independently of the suction fan and thus allow the work surface to be illuminated.

Light signal: A light signal turns on when the activated carbon filters need to be replaced.

No. of lights: 2

Type of light: LED

Light power: 1 W

Light color temperature (°K): 4000 °K

Maximum extraction capacity in free mode (P0): 673 m³/h

Motor power: 275 W

No. of filters: 2

Anti-grease filters: Aluminum

Filter change indicator: Yes

Minimum installation distance from gas hob: 750 mm

Minimum distance installation from electric hob: 650 mm

Motor inlet diameter: 150 mm

Non-return valve: Yes

PERFORMANCE / ENERGY LABEL strong>

A: Class A of Smeg appliances allows low energy consumption.

Energy efficiency class (EEC): A

Fluid efficiency class din friend (FDEC): A

Grease filtering efficiency class (GFEC): E

Lighting efficiency class (LEC): A

Consumption efficiency annual light (AEC): 46 kWh/a

Dynamic Fluid Efficiency (FDE): 31.7

Lighting Efficiency (LE): 111.8 lux/W

Efficiency filtering capacity (GFE): 56.9 %

Air flow at minimum speed (Qmin): 261 m³/h

Air flow at maximum speed (Qmax): 606 m³/h

Air flow rate at intensive speed (Qboost): 683 m³/h

Weighted acoustic power emission at minimum speed (SPEmin): 46 dB(A)

Weighted acoustic power emission at maximum speed (SPEmax): 65 dB(A)

Weighted acoustic power emission at intensive speed (SPEboost): 68 dB(A)

Absorption in stand-by (Ps): 0.49 W

Time increase factor (F): 0.9

Air flow measured in the condition of maximum efficiency ( Qbep): 329 m³/h

Air pressure measured in the c condition of maximum efficiency (Pbep): 466 Pa

Electrical power absorbed in condition of maximum efficiency (Wbep): 134 W

Nominal power of the lighting system (WL): 2 W

Average illumination of the hob lighting system (Emiddle): 246 lux

Sound level in the highest configuration (Lwa): 65 dB(A)

ELECTRICAL CONNECTION

Electrical connection ratings: 277 W

Voltage: 220-240 V

Frequency: 50- 60 Hz

Power cord length: 1500 mm

SPEED 1

Suction capacity (IEC 61591): 261 m³ /h

Noise level (IEC 60704-2-13): 46 dB(A)

Power: 199 W

SPEED 2

Suction capacity (IEC 61591): 436 m³/h

Noise level (IEC 60704-2-13): 58 dB(A)

Power: 219 W

SPEED 3

Suction capacity (IEC 61591): 606 m³/h

Noise level (IEC 60704-2-13): 6 5 dB(A)

Power: 233 W

INTENSIVE SPEED

Suction capacity (IEC 61591): 683 m³ /h

Noise level (IEC 60704-2-13): 68 dB(A)

Power: 228 W

LOGISTICS INFORMATION

Product dimensions (mm): 335x770x300

Width: 770 mm

Product depth (mm): 300 mm

Product height (mm): 335 mm

Net weight (kg): 11.150 kg

Gross weight (kg): 13.000 kg
