Miele DAW 1620 Active 60cm stainless steel wall hood

STAINLESS STEEL GREASE FILTER (10-LAYER) - Easy to use and effective against grease

Miele hoods are equipped with a 10-layer stainless steel metal grease filter and guarantee excellent grease separation. When removed, the integrated fall protection protects the hob from damage. The cover and filter frame are made of high-quality stainless steel, so that there is no visible discoloration when cleaning in the dishwasher and the filter remains aesthetically pleasing for a long time.

Product data sheet

TYPE

Wall-mounted extractor hood

MODE

Air circuit type Convertible

DESIGN

Color Stainless steel

COMFORT OF USE

Control electronic

EasySwitch

EFFICIENCY AND SUSTAINABILITY

Energy efficiency class (A+++ – D) A

Annual energy consumption in kWh/year 49.90

Fluid dynamic efficiency class A

Lighting efficiency class A

Grease filtering efficiency class B

FILTERING SYSTEM

Number of stainless steel metal grease filters 2

LIGHTING

LED

Number x Watt 1 x 3.2 W

Light intensity in Lx 390 lx

Color temperature in K 3500 Kelvin

EXTRACTOR

Double-sided suction

Alternating current motor (AC-Motor)

EXHAUST AIR

Air power level 1 (m³/h) 250

Air power level 2 (m³/h) 395

Air power intense level (m³/h) 640

Sound power level 1 (dB(A) re1pW) 52.00

Sound power level 1 (dB(A) re1pW) 62.00

Sound power intense level (dB(A) re1pW) 71.00

Sound pressure level 1 (dB(A) re20µPa) 38.00

Sound pressure level 2 (dB(A) re20µPa) 48.00

Sound pressure intense level (dB(A) re20µPa) 57.00

RECIRCULATION

Air power level 1 (m³/h) 235

Air power level 2 (m³/h) 390

Air power at intensive level (m³/h) 620

Sound power at level 1 (dB(A) re1pW) 53.00

Sound power at level 2 (dB(A) re1pW) 64.00

Sound power at intensive level (dB(A) re1pW) 74.00

Sound pressure at level 1 (dB(A) re20µPa) 39.00

Sound pressure at level 2 (dB(A) re20µPa) 50.00

Sound power at intensive level (dB(A) re1pW) 60.00

TECHNICAL DATA

673–993

803–1123

Overall height of exhaust hood and with external extractor min. in mm 673

Overall height of exhaust hood and with external extractor max. in mm 993

Overall height of recirculation hood min. in mm 803

Overall height of recirculation hood max. in mm 1123

Width of the hood body in mm 598

Height of the hood body in mm 50

Depth of the hood body in mm 500

Minimum distance from electric hobs in mm 450

Net weight in kg 13.40

Length of the power cable in m 1.40

Schuko plug

Total absorption in kW 0.25

Voltage in V 230

Protection in A 10

Frequency in Hz 50

Number of phases 1

INSTALLATION INSTRUCTIONS

Top air vent connection

Top and rear air vent connection

Diameter of vent sleeve in mm 150

Telescopic fireplace

EAN

4002516588429
