Smeg hobd482d2 induction hob with integrated hood 83 cm black

Revolutionizes the concept of design

The design of the new HOBD hob is minimalism in its purest form. A unique piece that holds a precious secret: at the centre of the induction glass ceramic hob is a powerful integrated hood capable of instantly removing odours, thanks to sophisticated technology and a filtering and extraction kit.

SPECIFICATIONS

Type

Family: Hob

Size: 80 cm

Type: Induction with integrated hood

Filtering: Exhaust

Built-in: Semi-flush with the possibility of flush-mounting

Power supply: Electric

Electronic control: Yes

EAN code: 8017709341879

Aesthetics

Colour: Black

Finish: Glass

Aesthetics: Universal

Material: Glass

Glass type: Ceramic

Type of control adjustment: EVO Slider

Position of controls: Front

Slider: Yes

LED control colour: Red

Glass edge: Straight

Grids: Stainless steel

Screen printing colour: Grey

Main oven programmes / functions

Total number of cooking zones: 4

Number of induction cooking zones: 4

Time programming options: Automatic switch-off

Number of cooking zones with booster: 4

Number of flexible zones: 2

Main on/off button: Yes

Power levels: 9

Options

Built-in hole: 490x750 mm

Multizone option: Yes

Flexible Zone Type: MultiZone

End of cooking timer: 4

Pause option: Yes

Minutes: 1

End of cooking acoustic alarm: Yes

Remaining time indicator: Yes

Power Limiter option: Yes Advance

Power Limiter option in W: 2800, 3500, 4500, 7400 W

Show Room Demo option: Yes

Button Lock / Child Safety option: Yes

Automatic heat maintenance function: Yes

Cleaning option: Yes

Quick start: Yes

Quick level selection: Yes

Cooking zones

1st zone position: Front left

2nd zone position: Rear left

3rd zone position: Rear right

4th zone position: Front right

1st zone type: Induction - Multizone

2nd zone type: Induction - Multizone

1st zone dimensions: 21.0x19.0 cm

2nd zone dimensions: 21.0x19.0 cm

3rd zone dimensions: 21.0x19.0 cm

4th zone dimensions: 21.0x19.0 cm

Multizone dimensions left: 39.0x21.0 cm

Multizone right dimensions: 39.0x21.0 cm

1st zone power: 2.10 kW

2nd zone power: 2.10 kW

3rd zone power: 2.10 kW

4th zone power: 2.10 kW

1st zone booster power: 3.00 kW

2nd zone booster power: 3.00 kW

3rd zone booster power: 3.00 kW

4th zone booster power: 3.00 kW

Left Multizone booster power: 3.70 kW

Right Multizone booster power: 3.70 kW

Technical Features

Automatic adjustment to the diameter of the pan: Yes

Automatic detection of pan position and control: Yes

Pan detection: Yes, min 9 cm

Automatic stop in case of overflow: Yes

Residual heat indicator: Yes

Protection against accidental ignition: Yes

Electrical Connection

Rated electrical connection data: 7620 W

Current: 33 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency: 50/60 Hz

Type of electrical cable supplied: Yes, Mono and Bi-phase

Power cord length: 120 cm

Controls (hood)

Hood control adjustment: Touch Capacitive

Led color: Red

Display: Yes

Programs / Functions (hood)

No. of speeds: 8

No. of intensive speeds: 2

Other functions: Auto-Vent

Hood time programming options: Delay

Other options: Filtering and Extractor Kit included

Auto-Vent: Yes

Technical Features (hood)

Maximum suction capacity in free mode (P0): 650 m³/h

Motor power: 220 W

Number of filters: 1

Grease filters: Aluminium

Charcoal filters as standard: YES regenerable

Filter change indicator: Yes

Speed 1

Suction capacity (IEC 61591): 230 m³/h

Noise level (IEC 60704-2-13): 49 dB(A)

Hood power: 40 W

Speed 2

Suction capacity (IEC 61591): 270 m³/h

Noise level (IEC 60704-2-13): 51 dB(A)

Hood power: 70 W

Speed 3

Extraction capacity (IEC 61591): 340 m³/h

Noise level (IEC 60704-2-13): 55 dB(A)

Hood power: 70 W

Speed 4

Extraction capacity (IEC 61591): 370 m³/h

Noise level (IEC 60704-2-13): 60 dB(A)

Hood power: 90 W

Speed 5

Extraction capacity (IEC 61591): 400 m³/h

Noise level (IEC 60704-2-13): 62 dB(A)

Pressure: 500 Pa

Hood power: 100 W

Speed 6

Extraction capacity (IEC 61591): 435 m³/h

Noise level (IEC 60704-2-13): 63 dB(A)

Pressure: 550 Pa

Hood power: 120 W

Speed 7

Extraction capacity (IEC 61591): 460 m³/h

Noise level (IEC 60704-2-13): 65 dB(A)

Pressure: 600 Pa

Hood power: 150 W

Speed 8

Suction capacity (IEC 61591): 500 m³/h

Noise level (IEC 60704-2-13): 68 dB(A)

Pressure: 620 Pa

Hood power: 170 W

Intensive speed

Suction capacity (IEC 61591): 540 m³/h

Noise level (IEC 60704-2-13): 70 dB(A)

Hood power: 180 W

Intensive speed 2

Suction capacity (IEC 61591): 630 m³/h

Noise level (IEC 60704-2-13): 73 dB(A)

Pressure: 630 Pa

Hood power: 220 W

Performance / Energy Label (hood)

Energy efficiency class (EEC): A+

Fluid dynamic efficiency class (FDEC): A

Grease filtering efficiency class (GFEC): B

Fluid dynamic efficiency (FDE): 32.10

Illumination efficiency (LE): 0.0 lux/W

Grease filtering efficiency (GFE): 85.1 %

Air flow rate at minimum speed (Qmin): 230 m³/h

Air flow rate at maximum speed (Qmax): 500 m³/h

Air flow rate at intensive speed (Qboost): 630 m³/h

Weighted sound power emission at minimum speed (SPEmin): 49 dB(A)

Weighted sound power emission at maximum speed (SPEmax): 68 dB(A)

Weighted sound power emission at intensive speed (SPEboost): 73 dB(A)

Power consumption in Off-mode (Po): 0.49 W

Time increase factor (F): 0.8

Energy efficiency index: 44.2

Air flow rate air pressure measured in the condition of maximum efficiency (Qbep): 328 m³/h

Air pressure measured in the condition of maximum efficiency (Pbep): 502 Pa

Electric power absorbed in the condition of maximum efficiency (Wbep): 139 W

Noise level in the highest configuration (Lwa): 68 dB(A)

Logistics Information

Product Dimensions (mm): 230x830x520

Product Depth: 520 mm

Product Width: 830 mm

Product Height: 230 mm

Net Weight (kg): 18,000 kg

Gross Weight (kg): 25,000 kg

Accessories Included

Filter kit and regenerable carbon filter included
